| Application scope: | Heat seal of blister box |
| Model: | TS700 |
| Main materials of the machine: | Aluminum alloy, 304 stainless steel |
| Dimensions: | 1000mm*850mm*450mm |
| Machine weight: | About 150 kg (excluding mould) |
| Power supply: | 220 V 50 / 60 Hz single phase 2.4 kw |
| Supply gas: | Pressure 5 bar - 8 bar, about 18 L / min |
| Heat seal size: | 400mm*700mm |
| Packaging depth: | Deepest100mm |
| Heat sealing speed: | Up to 12 cycles per minute, depending on the proficiency of the operator |
| Heat seal pressure: | 0.1-0.6 MPa adjustable |
